MV-1023
PCB Term Blk, 10.16mm, 23 Pole, Front wire, green Contact Altech for 3D Step File at info@altechcorp.com |
| 57A, 300V, 6-30AWG, 29.0mm height, modular |
- Color
- Green
- PCB Type
- Fixed
- Pin Spacing
- 10.16mm
- Connection Type
- Cage Clamp
- Series
- MV10
- Poles
- 23
- min Wire Size AWG
- 30
- max Wire size stranded AWG
- 6
- max Wire size solid AWG
- 6
- min Wire size sqmm
- 0.25
- max Wire size stranded sqmm
- 10.0
- max Wire size solid sqmm
- 16.0
- Current Rating UL
- 57A
- Voltage Rating UL
- 600V
- Current Rating IEC
- 70A
- Voltage Rating IEC
- 750V
- Height
- 29.00mm
- Length
- 233.64mm
- Number Rows
- 1
- Mounting
- Vertical
- Wire Entry
- 0°
- PCB Layout
- Linear Center
- Solder Pin Length
- 4.50mm
- PCB Hole Size
- 1.70mm
- Mounting Type
- Wave soldering
- Marking
- NA
- Standard Pack
- 50
- Packaging
- Carboard Box
- Weight (kg)
- 0.188600
- Country of Origin
- Italy
- Tariff Code
- 8536.69.4040
MV-1023
