Metal Body Limit Switches
Types
The scope of application for position switches has changed over time. Whereas position switches were previously used for the purpose of detecting end positions, today they are increasingly assuming functions designed to protect persons and products in machine, equipment and plant construction. The BERNSTEIN range of safety switches offers the right solution for the most diverse applications in many branches of industry. And when it comes to safety, users particularly appreciate the fact that they are able to procure and receive all the required safety switches and professional advice from one source. The decisive factors governing the selection of safety equipment include the ambient conditions, the installation situation and a risk analysis.
- Keyed Safety Switches
- Solenoid Locking Safety Switches
- Hinged Safety Switches
- Non-Contact Safety Switches
- Safety Rope Pull Switches
- Standard Rope Pull Switches
- Double Sided Rope Pull
- Switches Safety Relays
Metal Body Limit Switches
for Position, End of Travel, Production Detection & Safety Application
M49 Series
- Flat and compact design
- Pre-installed connecting cable (1m length) for quick and easy installation
- Top-mounting versions available
- Cable or M12 outlet on the side or at the bottom
- High protection class IP67
- For safety applications to DIN EN 60947-5-1 (positive break)
MN78 Series
- 2 or 4 Contact versions available
- Protection class IP66 and IP67 to EN 60529
- Enclosure: Die-cast aluminium
- Cover: Aluminium
- Actuator rotatable by 8 × 45°
- Cable entry M20 × 1.5
SN2 Series
- Protection class IP65 to VDE 0470 T1
- Enclosure: Die-cast aluminium
- Cover: Sheet aluminium
- Actuator can be repositioned by 4 x 90°
- Cable entry 3 x M20 x 1.5
- Connection designation to DIN EN 50013
- Metal actuators for high loads
- Graduated adjustment of the AH lever
D Series
- Protection class IP65 according to VDE 0470 T1
- Enclosure: Die-cast aluminium
- Cover: Sheet aluminium
- Actuator rotable by 4 x 90° (depending on type)
- Cable entries 2 x M20 x 1.5
- Connection designation conforming to DIN EN 50013
- Sturdy contacts
- Hard wearing guide bushes
