    MV-1008
    MV-1008

    MV-1008

    MV-1008

    PCB Term Blk, 10.16mm, 8 Pole, Front wire, green

    Data Sheet

    Contact Altech for 3D Step File at info@altechcorp.com


    57A, 300V, 6-30AWG, 29.0mm height, modular
    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    10.16mm
    Connection Type
    Cage Clamp
    Series
    MV10
    Poles
    8
    min Wire Size AWG
    30
    max Wire size stranded AWG
    6
    max Wire size solid AWG
    6
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    10.0
    max Wire size solid sqmm
    16.0
    Current Rating UL
    57A
    Voltage Rating UL
    600V
    Current Rating IEC
    70A
    Voltage Rating IEC
    750V
    Height
    29.00mm
    Length
    81.28mm
    Number Rows
    1
    Mounting
    Vertical
    Wire Entry
    0°
    PCB Layout
    Linear Center
    Solder Pin Length
    4.50mm
    PCB Hole Size
    1.70mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    50
    Packaging
    Carboard Box
    Weight (kg)
    0.065600
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
