SPCT 62/22 30/5 A VA 1 CL 5 - Current Transformers
SPCT 62/22 30/5 A VA 1 CL 5
SPCT 62/22 30/5 A VA 1 CL 5 - Current Transformers
Features
• Use with Different Bus Bar
• Panel Mount / Din Rail Mount (Optional Accessory)
• Accuracy: Class 0.5 to 5
DATA Sheet Link
< Product photo may vary depending on part number selection.
Analog / Digital Protection Relays
Protection
Altech is pleased to offer a variety of protection relays covering:
Phase Monitoring
Voltage Monitoring
Current Monitoring
Frequency Monitoring
Current Leakage / Ground Fault Monitoring Protection relays help to maintain systems and ensure that proper action is taken when a fault is detected. Such functions help to preserve productivity and operational effectiveness of integral components.
- Process Controllers - Operating Temperature
- 0 to 50°C (32 to 122°F)
- Process Controllers - Storage Temperature
- -5 to 50°C (23 to 122°F)
- Process Controllers - Humidity (Non-Condensing)
- 95% Relative Humidity
- Process Controllers - Rated Primary Rating
- 30A-4000A
- Process Controllers - Rated secondary Rating
- 5A
- Process Controllers - Rated Burden
- 1 VA-15 VA
- Process Controllers - Class of Accuracy
- 0.5-5
- Process Controllers - Thermal Nominal Continuous
- 120% of In Rated Current (Icth)
- Process Controllers - Thermal Short Circuit Current (LTH)
- Ith equals 60 X In for 1 sec.
- Process Controllers - Instrument security Factor
- FS greater than 5
- Process Controllers - Isolation Class
- E (120°C max)
- Process Controllers - Max Operating Voltage (Um)
- 720 V maximum
- Process Controllers - Isolation Test Voltage
- 3 kV AC (1 min.)
- Process Controllers - Nominal Rated Frequency
- AC 50Hz-60Hz
- Process Controllers - Wire Aperture (mm)
- DIA 22
- Process Controllers - Current Ratio
- 30/5
- Process Controllers - Burden in VA
- 1
- Process Controllers - Accuracy Class
- 5
