MVE177-7,5-V
PCB Term Blk, 7.50mm, 7 Pole, Front wire, green Contact Altech for 3D Step File at info@altechcorp.com |
Related products and accessories
| 20A, 300V, 14-30AWG, 13.5mm height, modular |
- Color
- Green
- PCB Type
- Fixed
- Pin Spacing
- 7.50mm
- Connection Type
- Box Clamp WP
- Series
- MVE17
- Poles
- 7
- min Wire Size AWG
- 30
- max Wire size stranded AWG
- 14
- max Wire size solid AWG
- 14
- min Wire size sqmm
- 0.25
- max Wire size stranded sqmm
- 2.50
- max Wire size solid sqmm
- 2.50
- Current Rating UL
- 20A
- Voltage Rating UL
- 300V
- Current Rating IEC
- 24A
- Voltage Rating IEC
- 750V
- Height
- 13.50mm
- Length
- 52.50mm
- Number Rows
- 1
- Mounting
- Vertical
- Wire Entry
- 0°
- PCB Layout
- Linear Center
- Solder Pin Length
- 4.00mm
- PCB Hole Size
- 1.50mm
- Mounting Type
- Wave soldering
- Marking
- NA
- Standard Pack
- 100
- Packaging
- Carboard Box
- Weight (kg)
- 0.008001
- Country of Origin
- Italy
- Tariff Code
- 8536.69.4040
