MIP252-5,08-IQ
PCB Term Blk, 5.08mm, 2 Pole, 45°, green |
Related products and accessories
| 24A, 300V, 12-30AWG, 12.5mm height, modular |
- Color
- Green
- PCB Type
- Fixed
- Pin Spacing
- 5.08mm
- Connection Type
- Cage Clamp
- Series
- MIP25
- Poles
- 2
- min Wire Size AWG
- 30
- max Wire size stranded AWG
- 12
- max Wire size solid AWG
- 12
- min Wire size sqmm
- 0.25
- max Wire size stranded sqmm
- 2.50
- max Wire size solid sqmm
- 4.00
- Current Rating UL
- 24A
- Voltage Rating UL
- 300V
- Current Rating IEC
- 24A
- Voltage Rating IEC
- 250V
- Height
- 12.50mm
- Length
- 10.16mm
- Number Rows
- 1
- Mounting
- Angled
- Wire Entry
- 45°
- PCB Layout
- Linear Center
- Solder Pin Length
- 4.80mm
- PCB Hole Size
- 1.50mm
- Mounting Type
- Wave soldering
- Marking
- NA
- Standard Pack
- 100
- Packaging
- Carboard Box
- Weight (kg)
- 0.002995
- Country of Origin
- Italy
- Tariff Code
- 8536.69.4040
MIP252-5,08-IQ
