    MVS2512-5,08-HS
    MVS2512-5,08-HS

    MVS2512-5,08-HS

    PCB Term Blk, 5.08mm, 12 Pole, Top wire, green

    Data Sheet

    Contact Altech for 3D Step File at info@altechcorp.com


    18A, 300V, 14-30AWG, 16.0mm height, raised

    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    5.08mm
    Connection Type
    Cage Clamp
    Series
    MVS25
    Poles
    12
    min Wire Size AWG
    30
    max Wire size stranded AWG
    14
    max Wire size solid AWG
    14
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    2.50
    max Wire size solid sqmm
    4.00
    Current Rating UL
    18A
    Voltage Rating UL
    300V
    Current Rating IEC
    24A
    Voltage Rating IEC
    450V
    Height
    16.00mm
    Length
    60.96mm
    Number Rows
    1
    Mounting
    horizontal
    Wire Entry
    90°
    PCB Layout
    Linear
    Solder Pin Length
    7.25mm
    PCB Hole Size
    1.50mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    100
    Packaging
    Carboard Box
    Weight (kg)
    0.022440
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
