MHE-1619
PCB Term Blk, 5.00mm, 19 Pole, Top wire, black Contact Altech for 3D Step File at info@altechcorp.com |
| 20A, 300V, 14-30AWG, 9.0mm height, modular |
- Color
- Black
- PCB Type
- Fixed
- Pin Spacing
- 5.00mm
- Connection Type
- Box Clamp WP
- Series
- MHE16
- Poles
- 19
- min Wire Size AWG
- 30
- max Wire size stranded AWG
- 14
- max Wire size solid AWG
- 14
- min Wire size sqmm
- 0.25
- max Wire size stranded sqmm
- 2.50
- max Wire size solid sqmm
- 4.00
- Current Rating UL
- 20A
- Voltage Rating UL
- 300V
- Current Rating IEC
- 16A
- Voltage Rating IEC
- 450V
- Height
- 9.00mm
- Length
- 95.00mm
- Number Rows
- 1
- Mounting
- horizontal
- Wire Entry
- 90°
- PCB Layout
- Linear
- Solder Pin Length
- 3.80mm
- PCB Hole Size
- 1.30mm
- Mounting Type
- Wave soldering
- Marking
- NA
- Standard Pack
- 100
- Packaging
- Carboard Box
- Weight (kg)
- 0.025669
- Country of Origin
- Italy
- Tariff Code
- 8536.69.4040
