MVS152-5-V-L

MVS152-5-V-L

MVS152-5-V-L

PCB Term Blk, 5.00mm, 2 Pole, Front wire, green

Downloadable 3D Image

17.5A, 300V, 16-30AWG, 13.2mm height, no dovetail

Color: Green
PCB Type: Fixed
Pin Spacing: 5.00mm
Connection Type: Cage Clamp
Series: MVS15
Poles: 2
min Wire Size AWG: 30
max Wire size stranded AWG: 16
max Wire size solid AWG: 16
min Wire size sqmm: 0.25
max Wire size stranded sqmm: 1.50
max Wire size solid sqmm: 2.50
Current Rating UL: 17.5A
Voltage Rating UL: 300V
Current Rating IEC: 17.5A
Voltage Rating IEC: 450V
Height: 13.20mm
Length: 10.00mm
Number Rows: 1
Mounting: Vertical
Wire Entry: 0°
PCB Layout: Linear Center
Solder Pin Length: 4.00mm
PCB Hole Size: 1.50mm
Mounting Type: Wave soldering
Marking: NA
Standard Pack: 200
Packaging: Carboard Box
Weight (kg): 0.002054
Country of Origin: Italy
Tariff Code: 8536.69.4040

Part Number MVS152-5-V-L
