    MH-1512
    MH-1512

    MH-1512

    PCB Term Blk, 5.00mm, 12 Pole, Top wire, green

    Data Sheet

    Downloadable 3D Image

    Related products and accessories


    13.5A, 300V, 16-30AWG, 8.1mm height, modular

    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    5.00mm
    Connection Type
    Cage Clamp
    Series
    MV15
    Poles
    12
    min Wire Size AWG
    30
    max Wire size stranded AWG
    16
    max Wire size solid AWG
    16
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    1.50
    max Wire size solid sqmm
    1.50
    Current Rating UL
    13.5A
    Voltage Rating UL
    300V
    Current Rating IEC
    13.5A
    Voltage Rating IEC
    250V
    Height
    8.10mm
    Length
    60.00mm
    Number Rows
    1
    Mounting
    horizontal
    Wire Entry
    90°
    PCB Layout
    Linear
    Solder Pin Length
    3.95mm
    PCB Hole Size
    1.30mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    100
    Packaging
    Carboard Box
    Weight (kg)
    0.010152
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
