    MBE-1524
    MBE-1524

    MBE-1524

    PCB Term Blk, 5.00mm, 24 Pole, Front wire, green

    Data Sheet

    Contact Altech for 3D Step File at info@altechcorp.com

    Related products and accessories


    20A, 300V, 14-30AWG, 10.2mm height, modular
    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    5.00mm
    Connection Type
    Box Clamp WP
    Series
    MBE15
    Poles
    24
    min Wire Size AWG
    30
    max Wire size stranded AWG
    14
    max Wire size solid AWG
    14
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    2.50
    max Wire size solid sqmm
    2.50
    Current Rating UL
    20A
    Voltage Rating UL
    300V
    Current Rating IEC
    24A
    Voltage Rating IEC
    450V
    Height
    10.20mm
    Length
    120.00mm
    Number Rows
    1
    Mounting
    Vertical
    Wire Entry
    0°
    PCB Layout
    Linear Center
    Solder Pin Length
    4.00mm
    PCB Hole Size
    1.50mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    50
    Packaging
    Carboard Box
    Weight (kg)
    0.021000
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
    MBE-1524
