    MI255-10,16-IT
    MI255-10,16-IT

    MI255-10,16-IT

    PCB Term Blk, 10.16mm, 5 Pole, 35°, green

    Data Sheet

    Contact Altech for 3D Step File at info@altechcorp.com


    16A, 300V, 14-30AWG, 16.3mm height, modular
    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    10.16mm
    Connection Type
    Cage Clamp
    Series
    MI25
    Poles
    5
    min Wire Size AWG
    30
    max Wire size stranded AWG
    14
    max Wire size solid AWG
    14
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    2.50
    max Wire size solid sqmm
    4.00
    Current Rating UL
    16A
    Voltage Rating UL
    300V
    Current Rating IEC
    16A
    Voltage Rating IEC
    750V
    Height
    16.30mm
    Length
    45.72mm
    Number Rows
    1
    Mounting
    Angled
    Wire Entry
    35°
    PCB Layout
    Linear Center
    Solder Pin Length
    4.50mm
    PCB Hole Size
    1.30mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    100
    Packaging
    Carboard Box
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
