    MV1316-3,81-H-L
    MV1316-3,81-H-L

    MV1316-3,81-H-L

    PCB Term Blk, 3.81mm, 16 Pole, Top wire, green

    Data Sheet

    Contact Altech for 3D Step File at info@altechcorp.com

    Related products and accessories



    12A, 300V, 16-30AWG, 7.3mm height, no dovetail

    Color
    Green
    PCB Type
    Fixed
    Pin Spacing
    3.81mm
    Connection Type
    Cage Clamp
    Series
    MV13
    Poles
    16
    min Wire Size AWG
    30
    max Wire size stranded AWG
    16
    max Wire size solid AWG
    16
    min Wire size sqmm
    0.25
    max Wire size stranded sqmm
    1.00
    max Wire size solid sqmm
    1.50
    Current Rating UL
    12A
    Voltage Rating UL
    300V
    Current Rating IEC
    13.50A
    Voltage Rating IEC
    130V
    Height
    7.30mm
    Length
    60.96mm
    Number Rows
    1
    Mounting
    horizontal
    Wire Entry
    90°
    PCB Layout
    Linear
    Solder Pin Length
    3.20mm
    PCB Hole Size
    1.30mm
    Mounting Type
    Wave soldering
    Marking
    NA
    Standard Pack
    100
    Packaging
    Carboard Box
    Weight (kg)
    0.006888
    Country of Origin
    Italy
    Tariff Code
    8536.69.4040
    MV1316-3,81-H-L
