MV1311-3,81-V-L

MV1311-3,81-V-L

MV1311-3,81-V-L

PCB Term Blk, 3.81mm, 11 Pole, Front wire, green

Downloadable 3D Image

12A, 300V, 16-30AWG, 8.5mm height, no dovetail

Color: Green
PCB Type: Fixed
Pin Spacing: 3.81mm
Connection Type: Cage Clamp
Series: MV13
Poles: 11
min Wire Size AWG: 30
max Wire size stranded AWG: 16
max Wire size solid AWG: 16
min Wire size sqmm: 0.25
max Wire size stranded sqmm: 1.00
max Wire size solid sqmm: 1.50
Current Rating UL: 12A
Voltage Rating UL: 300V
Current Rating IEC: 13.5A
Voltage Rating IEC: 130V
Height: 8.50mm
Length: 41.91mm
Number Rows: 1
Mounting: Vertical
Wire Entry: 0°
PCB Layout: Linear Center
Solder Pin Length: 3.50mm
PCB Hole Size: 1.30mm
Mounting Type: Wave soldering
Marking: NA
Standard Pack: 100
Packaging: Carboard Box
Weight (kg): 0.004895
Country of Origin: Italy
Tariff Code: 8536.69.4040

Part Number MV1311-3,81-V-L
