    Dual Wire Insulated

    Dual Wire Ferrules have larger diameters and special shaped sleeves that accept two conductors of the same or different size.They provide an efficient connection of multiple wires in the same terminal clamp or simplify wire jumpering between terminal clamps.They are color coded with the same convention as the insulated DIN standard ferrules.

    To ensure efficient ferrule crimping always select the smallest ferrule diameter that fits the wire and use only professional crimping tools.

      • Sleeve: polypropylene
      • Tube: tin plated copper

    3 page DATA SHEET

    Product photo/drawing may vary depending on part number selection.



    Color
    Gray
    AWG
    2 x 18
    mm²
    2 x 0.75
    Standard
    Industry
    L₁
    14.6
    Barrel Length (L₂ mm)
    8.2
    D₁
    1.7
    S₁
    0.15
    S₂
    0.3
    Ferrule Type
    Insulated
    A
    5.5
    B
    3
    2775.0
