- Color
- Light grey
- Series
- KO4300
- Electrical
- 16A
22-12 AWG
300V - Temperature Range
- Up to 125°C (257°F)
- Standard Package
- 1
- Customizable
- Yes
- Terminals Count
- 16
- Termination Type
- Screw Clamp
- DIN Rail
- 35
- Housing Material
- Glass-filled Polycarbonate
- Terminal Block Material
- Glass-filled Polyamide
- Recommended Torque
- 0.8Nm
- Max. PCB's
- (2) Vertical
- PCB Connection
- Machine Solder
90.900
No reviews
Tap to zoom
