    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC
    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC
    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC
    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC
    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC
    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC

    Safety Relay : OA 5644 : 8A : 110V : 3 NO - 1 NC

    Contact Material

    Current Rating
    8A
    Rated Voltage
    110V
    Contact Arrangement
    3 NO - 1 NC
    Voltage Range
    77.0- 143.0V
    Protection Rating
    RTIII wash proof
    Series
    OA 5644
    Output Contacts
    4
    International Approvals
    TUV
    UL
    cUL
    Force-guided Contacts
    All gold flash plated
    Coil Resistance (10%)
    18500Ω
    56.OA44.1131C
