KU4100 Series 16 Terminal - Screw Clamp
16 Terminal, High Current Terminals, PCB Blocks, 35 mm DIN Rail
- Color
- Black Base
Light Gray Cover - Series
- KU4100
- Electrical
- 20-8 AWG
40A
250V - Temperature Range
- Up to 115°C (239°F)
- Standard Package
- 1
- Customizable
- Yes
- Terminals Count
- 16
- Termination Type
- Screw Clamp
- DIN Rail
- 35
- Housing Material
- Glass-filled Polycarbonate
- Recommended Torque
- 1.2Nm
- PCB Connection
- Machine Solder
- PCB Locations
- (2) Vertical
Perpendicular
91.813
