Power Supplies

Click here online catalog.

Slim Line Power Supplies

Webpage Links	Output		Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
Webpage Links	V [V DC]	I [A]	Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
PS-S1005	5V DC	2A	85 ~ 264V AC; 120 ~ 370V DC	±5%	77%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S1012	12V DC	0.84A	85 ~ 264V AC; 120 ~ 370V DC	±3%	81%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S1015	15V DC	0.67A	85 ~ 264V AC; 120 ~ 370V DC	±3%	81%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S1024	24V DC	0.42A	85 ~ 264V AC; 120 ~ 370V DC	±2%	84%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S2005	5V DC	3A	85 ~ 264V AC; 120 ~ 370V DC	±2%	76%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S2012	12V DC	1.67A	85 ~ 264V AC; 120 ~ 370V DC	±1%	80%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S2015	15V DC	1.34A	85 ~ 264V AC; 120 ~ 370V DC	±1%	81%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S2024	24V DC	1A	85 ~ 264V AC; 120 ~ 370V DC	±1%	84%	22.5x90x100 mm³; 0.88x3.54x3.95 in³
PS-S4005	5V DC	6A	85 ~ 264V AC; 120 ~ 370V DC	±2%	79%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S4012	12V DC	3.33A	85 ~ 264V AC; 120 ~ 370V DC	±1%	86%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S4024	24V DC	1.7A	85 ~ 264V AC; 120 ~ 370V DC	±1%	88%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S4048	48V DC	0.83A	85 ~ 264V AC; 120 ~ 370V DC	±1%	88%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S6005	5V DC	10A	85 ~ 264V AC; 120 ~ 370V DC	±2%	79%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S6012	12V DC	5A	85 ~ 264V AC; 120 ~ 370V DC	±1%	86%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S6024	24V DC	2.5A	85 ~ 264V AC; 120 ~ 370V DC	±1%	88%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S6048	48V DC	1.25A	85 ~ 264V AC; 120 ~ 370V DC	±1%	88%	40 x90x100 mm³; 1.57x3.54x3.95 in³
PS-S10012	N/A	N/A	85 ~ 264V AC; 120 ~ 370V DC	N/A	N/A	55 x90x100 mm³; 2.16x3.54x3.95 in³
PS-S10024	N/A	N/A	85 ~ 264V AC; 120 ~ 370V DC	N/A	N/A	55 x90x100 mm³; 2.16x3.54x3.95 in³
PS-S10048	N/A	N/A	85 ~ 264V AC; 120 ~ 370V DC	N/A	N/A	55 x90x100 mm³; 2.16x3.54x3.95 in³

Single Phase Power Supplies

Webpage Links	Output		Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
Webpage Links	V [V DC]	I [A]	Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
PS-1505	5V DC	2.4A	85 ~ 264V AC; 120 ~ 370V DC	±2%	77%	25x93x56 mm³; 0.98x3.66x2.05 in³
PS-1512	12V DC	1.25A	85 ~ 264V AC; 120 ~ 370V DC	±1%	84%	25x93x56 mm³; 0.98x3.66x2.05 in³
PS-1515	15V DC	1A	85 ~ 264V AC; 120 ~ 370V DC	±1%	83.5%	25x93x56 mm³; 0.98x3.66x2.05 in³
PS-1524	24V DC	0.63A	85 ~ 264V AC; 120 ~ 370V DC	±1%	85%	25x93x56 mm³; 0.98x3.66x2.05 in³
PS-3005	5V DC	3A	85 ~ 264V AC; 120 ~ 370V DC	±2%	74%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-3012	12V DC	2A	85 ~ 264V AC; 120 ~ 370V DC	±1%	81%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-3015	15V DC	2A	85 ~ 264V AC; 120 ~ 370V DC	±1%	82%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-3024	24V DC	1.5A	85 ~ 264V AC; 120 ~ 370V DC	±1%	83%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-4505	5V DC	5A	85 ~ 264V AC; 120 ~ 370V DC	±2%	72%	78x93x67 mm³; 3.07x3.66x2.64 in³
PS-4512	12V DC	3.5A	85 ~ 264V AC; 120 ~ 370V DC	±1%	77%	78x93x67 mm³; 3.07x3.66x2.64 in³
PS-4515	15V DC	2.8A	85 ~ 264V AC; 120 ~ 370V DC	±1%	77%	78x93x67 mm³; 3.07x3.66x2.64 in³
PS-4524	24V DC	2A	85 ~ 264V AC; 120 ~ 370V DC	±1%	80%	78x93x67 mm³; 3.07x3.66x2.64 in³
PS-6005	5V DC	6.5A	88 ~ 264V AC; 124 ~ 370V DC	±2%	76%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-6012	12V DC	4.5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	82%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-6015	15V DC	4A	88 ~ 264V AC; 124 ~ 370V DC	±1%	83%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-6024	24V DC	2.5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	84%	78x93x56 mm³; 3.07x3.66x2.05 in³
PS-10012	12V DC	7.5A	88 ~ 264V AC; 124 ~ 370V DC	±2%	87%	100x93x56 mm³; 3.93x3.66x2.05 in³	N/A
PS-10015	15V DC	6.5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	87%	100x93x56 mm³; 3.93x3.66x2.05 in³	N/A
PS-10024	24V DC	4.2A	88 ~ 264V AC; 124 ~ 370V DC	±1%	89%	100x93x56 mm³; 3.93x3.66x2.05 in³	N/A
PS-7512	12V DC	6.3A	85 ~ 264V AC; 120 ~ 370V DC	±2%	76%	55.5x125x100 mm³; 2.20x4.95x3.95 in³
PS-7524	24V DC	3.2A	85 ~ 264V AC; 120 ~ 370V DC	±1%	80%	55.5x125x100 mm³; 2.20x4.95x3.95 in³
PS-7548	48V DC	1.6A	85 ~ 264V AC; 120 ~ 370V DC	±1%	81%	55.5x125x100 mm³; 2.20x4.95x3.95 in³
PS-12012	12V DC	10A	88 ~ 132VAC/176 ~ 264VAC by switch; 248 ~ 370VDC	±2%	80%	65.5x125x100 mm³; 2.56x4.95x3.95 in³
PS-12024	24V DC	5A	88 ~ 132VAC/176 ~ 264VAC by switch; 248 ~ 370VDC	±1%	84%	65.5x125x100 mm³; 2.56x4.95x3.95 in³
PS-12048	48V DC	2.5A	88 ~ 132VAC/176 ~ 264VAC by switch; 248 ~ 370VDC	±1%	85%	65.5x125x100 mm³; 2.56x4.95x3.95 in³
PS-C12012	12V DC	10A	88 ~ 264V AC; 124 ~ 370V DC	±1%	89%	40x125.2x113.5 mm³; 1.6x4.93x4.47 in³
PS-C12024	24V DC	5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	91%	40x125.2x113.5 mm³; 1.6x4.93x4.47 in³
PS-C12048	48V DC	2.5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	90%	40x125.2x113.5 mm³; 1.6x4.93x4.47 in³
PS-C24024	24V DC	10A	88 ~ 264V AC; 124 ~ 370V DC	±1%	93%	63x125.2x113 mm³; 2.48x4.93x4.45 in³
PS-C24048	48V DC	5A	88 ~ 264V AC; 124 ~ 370V DC	±1%	93%	63x125.2x113 mm³; 2.48x4.93x4.45 in³
PS-C48024	24V DC	20A	90 ~ 264V AC; 127 ~ 370V DC	±1%	94%	85.5x125.2x128.5 mm³; 3.37x4.93x5.01 in³
PS-C48048	48V DC	10A	90 ~ 264V AC; 127 ~ 370V DC	±1%	94%	85.5x125.2x128.5 mm³; 3.37x4.93x5.01 in³
PSH-12024	24V DC	5A	340 ~ 550V AC; 480 ~ 780V DC	±1%	85%	65.5x125x100 mm³; 2.56x4.95x3.95 in³
PSH-12048	48V DC	2.5A	340 ~ 550V AC; 480 ~ 780V DC	±1%	86%	65.5x125x100 mm³; 2.56x4.95x3.95 in³
PSP-24024	24V DC	10A	85 ~ 264V AC; 120 ~ 370V DC	±1%	84%	125x125x100 mm³; 4.95x4.95x3.95 in³
PSP-24048	48V DC	5A	85 ~ 264V AC; 120 ~ 370V DC	±1%	85%	125x125x100 mm³; 4.95x4.95x3.95 in³
PSP-48024	24V DC	20A	180 ~ 264V AC; 120 ~ 370V DC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PSP-48048	48V DC	10A	180 ~ 264V AC; 120 ~ 370V DC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PSP-480S24	24V DC	20A	90 ~ 132VAC/180 ~ 264VAC by switch; 254 ~ 370VDC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PSP-480S48	48V DC	10A	90 ~ 132VAC/180 ~ 264VAC by switch; 254 ~ 370VDC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PS-C48024	24V DC	20A	90 ~ 264VAC/ 127 ~ 370VAC	±1.2%	94%	88.5x125.2x128.5 mm³; 3.48x4.95x5.06 in³
PS-C48048	48V DC	10A	90 ~ 264VAC/ 127 ~ 370VAC	±1.0%	94%	88.5x125.2x128.5 mm³; 3.48x4.95x5.06 in³

Three Phase Power Supplies

Webpage Links	Output		Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
Webpage Links	V [V DC]	I [A]	Input voltage [V AC;V DC]	Tol. [%]	Eff. [%]	W x H x D [mm^3; in³]	PDF File
PST-24024	24V DC	10A	Three-Phase 340 ~ 550VAC; 480 ~ 780VDC	±1%	89%	125x125x100 mm³; 4.95x4.95x3.95 in³
PST-24048	48V DC	5A	Three-Phase 340 ~ 550VAC; 480 ~ 780VDC	±1%	89%	125x125x100 mm³; 4.95x4.95x3.95 in³
PST-48024	24V DC	20A	Three-Phase 340 ~ 550VAC; 480 ~ 780VDC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PST-48048	48V DC	10A	Three-Phase 340 ~ 550VAC; 480 ~ 780VDC	±1%	89%	227x125x100 mm³; 8.95x4.95x3.95 in³
PST-96024	24V DC	40A	Three-Phase 340 ~ 550VAC	±1%	91%	276x125x100 mm³; 10.87x4.95x3.95 in³
PST-96048	48V DC	20A	Three-Phase 340 ~ 550VAC	±1%	91%	276x125x100 mm³; 10.87x4.95x3.95 in³

Power Supply Accessories

Webpage Links	DC Input voltage	Description	W x H x D [mm^3; in³]	PDF File

PS-RDN20	21 ~ 28V	Power supply redundancy moudle	55.5x125x100 mm³; 2.20x4.95x3.95 in³
PS-UPS40	24 ~ 29V	Battery controller for DIN rail UPS system	55.5x125x100 mm³; 2.20x4.95x3.95 in³
