CB Battery Chargers
Single Phase
With the CB Battery Charger Line, Altech offers a highly reliable battery management solution. Operating at single phase Input Voltages of 115-230-277 VAC, the devices supply an Output of 12VDC and up to 35A or 24VDC and up to 20A.
Equipped with microcontrollers, the CB line offers fully automated multi-stage charging that will expand the batterie's life significantly. Several diagnostic and monitoring features ensure easy handling and a high amount of transparency during daily operation.
Altech's CB line battery chargers are based on the switching technology which allows much higher efficiency as well as smaller and lighter devices. Aditionally, several standard safety and protection features ensure safe installation and operation.
Features:
- Fully automated charging
- Three charging modes
- Compact, rugged metal case
- Available in 12VDC and 24VDC
- Suitable for most common battery types
- Adjustable charging current
- Easy battery diagnosis and fault identification either by LED or external devices connected to fault status contacts
- High efficiency up to 91% through switching technology
- Several output protection features such as short circuit, overload, deep battery discharge etc.
- DIN rail mounting
- Small size
- 3 year warranty
|
| CB-Line Single Phase Battery Charger 12VDC |
| Nominal Input Voltage |
115-230-277VAC |
| Output Voltage |
12VDC |
| Output Current |
3, 6, 10, 35A |
| Adjustable Charging Current |
20%-100% of Output Current |
| Working temperature: |
-25°C to 70°C |
| EMC standards: |
IEC/EN 60335-2-29,EN60950/UL1950,Electrical |
| |
safety,89/336/EEC,EMCDirective,2006/95/EC
(Low
Voltage),DIN41773 |
| |
(Charging cycle),Emission:IEC 61000-6-4,
Immunity:IEC
61000-6-2.CE |
| |
|
| |
|
| |
| CB-Line Single Phase Battery Charger 24VDC |
| Nominal Input Voltage |
115-230-277VAC |
| Output Voltage |
24VDC |
| Output Current |
3, 5, 10, 20A |
| Adjustable Charging Current |
20%-100% of Output Current |
| Working temperature: |
-25°C to 70°C |
| EMC standards: |
IEC/EN 60335-2-29,EN60950/UL1950,Electrical |
| |
safety,89/336/EEC,EMCDirective,2006/95/EC
(Low
Voltage),DIN41773 |
| |
(Charging cycle),Emission:IEC 61000-6-4,
Immunity: IEC
61000-6-2.CE |
| |
|
 PRODUCT SERIES selection chart
make a choice below
| 12VDC Single Phase DIN Rail Battery Chargers |
| Cat. No. |
Size |
Input |
Output* |
Recovery Charge |
Trickle Charge |
Boost Charge |
| |
|
VAC |
VDC |
A |
VDC |
VDC |
VDC |
| CB123A |
1 |
115-230-277 |
12 |
3 |
2-7 |
13.75 |
14.4 |
| CB126A |
1 |
115-230-277 |
12 |
6 |
2-7 |
13.75 |
14.4 |
| CB1210A |
2 |
115-230-277 |
12 |
10 |
2-9 |
13.75 |
14.4 |
| CB1235A |
4 |
115-230-277 |
12 |
35 |
2-9 |
13.75 |
14.4 |
| *= Output Current can be adjusted from 20%-100% of value given
above |
|
| |
| 24VDC Single Phase DIN Rail Battery Chargers |
| Cat. No. |
Size |
Input |
Output* |
Recovery Charge |
Trickle Charge |
Boost Charge |
| |
|
VAC |
VDC |
A |
VDC |
VDC |
VDC |
| CB243A |
1 |
115-230-277 |
24 |
3 |
2-16 |
27.5 |
28.8 |
| CB245A |
2 |
115-230-277 |
24 |
5 |
2-18 |
27.5 |
28.8 |
| CB2410AC |
3 |
115-230-277 |
24 |
10 |
2-18 |
27.5 |
28.8 |
| CB2420A |
4 |
115-230-277 |
24 |
20 |
2-18 |
27.5 |
28.8 |
| *= Output Current can be adjusted from 20%-100% of value given
above |
|
|
